ISR Performance Front Mount Intercooler Kit - Nissan 240sx 2JZ Swap

The ISR Performance front mount intercooler kit for the 2JZ swapped Nissan 240SX removes the biggest piping headache from a factory twin turbo 2JZ-GTE in an S chassis. It pairs an ISR M spec S chassis intercooler core with piping routed specifically for the stock twins and stock intake manifold sitting on ISR Performance swap mounts in an S13 or S14.

Kit Design

• ISR M spec S chassis front mount intercooler core
• Four intercooler pipes shaped to connect the factory 2JZ twin turbo outlet to the factory intake manifold in the S chassis engine bay
• Six intercooler couplers
• Twelve T-bolt clamps
• Built around the ISR Performance JZ swap mounts, so the engine position matches the piping

Fitment

Nissan 240SX S13 and S14 chassis with a 2JZ-GTE swap running the factory twin turbos and factory intake manifold, mounted on ISR Performance JZ swap mounts. This kit will not work with 1JZ engines.

In the Box

• 4x Intercooler pipes
• 1x M spec intercooler core
• 6x Intercooler couplers
• 12x T-bolt clamps

Why Buy a Kit Instead of Fabricating

A 2JZ with stock twins in a 240SX has a compressor outlet on the passenger side and a throttle body up front, and getting piping around the radiator, headlights and steering on an S chassis takes a lot of trial fitting. This kit gives you the proven route with the core sized for the S chassis front end. Mock up all four pipes with the couplers loose, check clearance to the bumper support and radiator, then tighten the T-bolt clamps in sequence from the turbo outlet forward.

All ISR Performance products are designed for off-road use only.
